Future light MH-860 - Description of the device

31
Description of the device
MH-860
3
2
1
7
4
56
FUSE
POWER
SUPPLY
POWER
910
8
DMX IN
SERIAL DATA LINK
1 = GND
2 = SIG.
3 = SIG. +
DMX OUT
LIGHTING CONTROLPROTOCOL:
DMX 512 4µs BY USITT
11
12
13
14
15
16
1
- Projector-head
2
- Yoke
3
- Left side panel
4
- Base
5
- Control Board
6
- Right side panel
7
- Carring handles
Left side panel:
8
- Power-switch
9
- Powercord
10
- Fuseholder
Right side panel:
11
- DMX-output
12
- DMX-input
Control Board:
13
- Mode-button
14
- Display
15
- Enter-button
16
- Up/Down-buttons
