24
4.1.9 Channel 9 - Dimmer, frost, correction filters, 3-facet prism :
0 Closed
1 - 63 Soft slow dimmer
64 - 95 Open position (hole)
96 - 127 Frost filter
128 - 159 3-facet prisma
160 - 191 3200 K correction filters
192 - 223 5600 K correction filters
224 - 255 UV filter
4.1.10 Channel 10 - No function
4.1.11 Channel 11 - Rotating gobos, cont. rotation
0 - 31 Open
32 - 63 Rot. gobo 1 (dichroic multicolor)
64 - 95 Rot. gobo 2 (dichroic)
96 - 127 Rot. gobo 3 (glass)
128 - 159 Rot. gobo 4 (glass)
160 - 191 Rot. gobo 5 (metal)
192 - 223 Rot. gobo 6 (metal)
224 - 255 Rot. gobo wheel cont. rotation slow to fast
4.1.12 Channel 12 - Rotating gobo index, rotating gobo rotation
0 - 127 Gobo indexing
128 - 191 Forwards gobo rotation from fast to slow
192 No rotation
193 - 255 Backwards gobo rotation from slow to fast
4.1.13 Channel 13 - Iris
0 Open
1 - 179 Max. diameter to min. diameter
180 - 191 Closed (enabled with channel 8 from 46 - 63,
this is open position at static gobo wheel)
192 - 223 Pulse closing slow to fast
224 - 255 Pulse opening fast to slow
Pulse closing and opening to the black-out is enabled with channel 8 from 46 - 63.
4.2 Function of the control channels - 8 bit protocol
5. Addressing the SC-740
The control board on the top side of the SC-740 allows you to assign the DMX fixture address, which is defined as
the first channel from which the SC-740 will respond to the controller.
If you set, for example, the address to channel 5, the SC-740 will use the channel 5 to 17 for control.
Please, be sure that you don’t have any overlapping channels in order to control each SC-740 correctly and
independently from any other fixture on the DMX data link.
If two, three or more SC-740 are addressed similarly, they will work similarly.
DMX
Channel
12345678 91011
Function PAN TILT
PAN/TILT
SPEED
FAN
ON/OFF
LAMP
COLOURS
GOBOS
STROBO
EFECTS
PRISM
DIMMER
NO
FUNCTION
ROTATING
GOBOS
GOBO
ROTATION
IRIS
