Appendix 1 – DVR Specifications
Dimensions: Height / Width / Depth
185mm (7.28”) / 186mm (7.32”) / 315mm (12.41”)
12.5 or 25 kHz programmable
DC Current Drain
RPTR Off
Standby/Receive
Transmit
0.01 A Max
0.8 A Max
4.5 A Max
Protection Against Liquids
External Connectors
Antenna
Computer Interface
Equipment Type Acceptance
LO6-DVRSVHF
2098B-DVRSVHF
LO6-DVRSUHF
2098B-DVRSUHF
LO6-DVRS700
2098B-DVRS700
LO6-DVRS800
2098B-DVRS800
Transmitter Specification
Power Output at TX Connector
Standalone Mode:
FCC Simultaneous DVRS
Repeated and Mobile Operation:
20 W Max. (programmable per channel from
1 W Min.)
5W, 6W, 10W or 20W Max. (programmable
per channel from 1 W Min.)
Refer to RF Safety Booklet for maximum
allowed power output for specific approved
DVRS, Mobile Radio and antenna
combinations
Maximum DVRS power output is
programmed by authorized service
personnel at time of DVRS installation in
accordance with approved DVRS, Mobile
Radio and antenna combinations.
Power output cannot be changed by the
operator
15 sec to 15 min or Disabled
FM Hum and Noise 12.5 / 25 kHz
+1, -3 dB of 6 dB / octave pre-emphasis
characteristic over 300 Hz – 3 kHz
