G-Lab Guitar System Controller - Package Content; Structure

4
Package content
Guitar System Controller unit - Product code 00519
GSC power supply adapter - Product code 01597 - for Europa market, or
Product code 01598 - for US market
Two 9V 40 cm cables - Product code 00805
Two 9V 80 cm cables - Product code 00806
User’s Manual
Structure
1 - Preset footswitches from 1 to 5
2 - OUT 9V DC output’s overloading indicator (effect’s power supply)
3 - Voltage failure indicator (voltage below 11V or above 15V)
4 - Activated loops’ (LOOP1 to LOOP4) indicators (lit when a loop is ON)
5 - SW1 to SW4 outputs’ status indicators
6 - Presets indicators
7 - LOOP programming button
8 - Banks indicators
9 - SWITCH programming button
10 - Memory access LOCK indicator
11 - MIDI programming button
12 - DEF footswitch with definable function
13 - Lowered volume control analog knob
14 - Memory access lock switch
12
1
2
3
4
5
6
7
8
9
10
11
13
14
