Rack Installation
This chapter provides instructions for preparing and mounting your chassis in a rack.
Installing the System into a Rack
This section provides information on installing the chassis into a rack unit with the rails provided.
There are a variety of rack units on the market, which may mean that the assembly procedure will
differ slightly from the instructions provided. You should also refer to the installation instructions
that came with the rack unit you are using.
Note: This rail will fit a rack between 26.5” and 36.4” deep.
Identifying the Sections of the Rack Rails
The chassis package includes two rail assemblies. Each assembly consists of three sections: An inner
rail that secures directly to the chassis, an outer rail that secures to the rack, and a middle rail which
extends from the outer rail. These assemblies are specifically designed for the left and right side of
the chassis.
Releasing the Inner Rail
Each inner rail has a locking latch. This latch prevents the server from coming completely out of the
rack when the chassis is pulled out for servicing.
To mount the rail onto the chassis, first release the inner rail from the outer rails.
Releasing Inner Rail from the Outer Rails
1. Pull the inner rail out of the outer rail until it is fully extended as illustrated below.
2. Press the locking tab down to release the inner rail.
3. Pull the inner rail all the way out.
4. Repeat for the other outer rail.
Installing the Inner Rails on the Chassis
1. Identify the left and right inner rails. They are labeled.
2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the
chassis with the holes in the inner rail.
3. Slide the inner rail forward toward the front of the chassis until the quick release bracket snaps
into place, securing the rail to the chassis.
4. Optionally, you can further secure the inner rail to the chassis with a screw.
5. Repeat for the other inner rail.
Installing the Outer Rails onto the Rack
1. Press upward on the locking tab at the rear end of the middle rail.
