Administrative Tool
p. 66
MTU Media Transfer Unit - the size of the packet pay-
load for the this interface
Wake-on-LAN Toggle to enable Wake-on-LAN if packets arrive
at this interface
Options Additional device settings, e.g. ‘autoneg off
speed 100 duplex full’. See manual page for
more details
• Under IPv4 choose either static or DHCP as the method.
• Not changing any other settings, save the new bond configuration. Bond0 should display in the
list with a DHCP IP generated.
• Log out of the admin tool after getting IP for bond0 interface, then login to the admin tool with
bond0 IP instead.
• Navigate back to Connect > Network > Interfaces and delete eth0 interface.
• After deleting eth0 successfully edit bond0 interface and add eth0 slave to bond interface then
save.
• bond0 should now have all 4 Ethernet ports as slave members; IP should not have changed.
• Remember to add all four ports on switch side to be trunk members in LACP Lag type
configuration as well.
Once a new bond connection has been created, use “Edit Ethernet connection” dialog for its
configuration.
