G-Tek GT-U1M - Water & Drainage Connections; Water connection; Water supply; Drainage

Global-Tek (Singapore) Pte Ltd
Page
7
Water connection
Caution
: c heck water inlet pressure after connection, if flowing pressure below 1 kg/cm
2
,a
water pressure pump (to be provided by other supplier) is needed, if static pressure is higher than 3
kg/cm
2
, a water pressure reducer (to be provided by other supplier) is needed.
a
Warning: Water pipe connection must comply with relative local hygiene safety ordnances
and plumbing code.
Water supply
Connect the water inlet hose (3/4”thread) with water supply valve.
Relative heating power
Water inlet temp.
Water flow pressure
o
C
o
F Bar kg/cm
2
4.5 Kw rinse heating
30～50 86～122 1～3 1～3
Drainage
Connection the drain pipe (1
1
/
2
”) under the wash tank with an appropriate drainage (drain
capacity should be a t least 95.5 L/min.)
