3. Preparation for use
3.1 Safety instructions for mounting and installation
Danger to life due to electric shock!
Read the safety instructions in chapter„1.2 Safety instructions“ on page4 without fail prior
to assembly and installation.
DANGER
3.2 Layout of compact control unit
2
43
1
1a
a
b
c
g
e
d
f
Layout of compact control unit RZ 25
Components
1 Housing
1a Protective-conductor terminal in
the housing
2 Power supply unit
3 Batteries
4 Board
Board
a Drive connection
b Connections for components
with terminal resistors
c Fuses
d Service interface
e Jumper J1, J2 and pin connectors
f DIP switch and potentiometer
g Display LEDs and reset push-
button
4
