PORTABLE BUT INDUSTRIAL LASER MARKING MACHINE
23
Check Enable,Object Overall Calc,Cross Fill,Select Types(As shown in
the figure)Angle:45 Line:0.02 after setting the parameters, click OK.
Modify the reference value of the total number of processes total：
50(The number of processing times can be adjusted appropriately accord-
ing to the processing depth)
Pen number reference value:Speed 1000mm/s Power 80% Frequency
30khz.
Complete the setting and start engraving processing.
Select the file and click Fill , modify parameter.
Open the software,click on the vector file icon select the file,
click open,and import the canvas.
Modify the file size and center the file on the canvas（You can also use
the center button )
IX.Deep Engraving Tutorial
