6
PRODUCT DIAGRAM
PRODUCT DIAGRAM
1. Control Panel
2. Display Screen
3. Door Button
4. Oven Window
5. Top Heating Element
6. Upper Convection Fan
7. Glass Turntable
8. Roller Ring
9. Shaft
10. Baking and Roasting Pan
11. Air Fry Kit
12. Wave Guide (Please do not remove the
mica plate covering the wave guide)
13. Door Safety Lock System
2
1
3
4
5 6 7
89
10
11
12
13
