7.1 Connector of PCBA
7.2 Dishwasher Strip Circuit s
The following individual circuit s are for use in diagnoses. Do not cont inue wit h
the diagnoses of t he appliance if a fuse is blown, a circuit breaker is t ripped, or if
there is less t han a 230 volt power supply at t he wall outlet .
■ Unplug dishwasher or disconnect power.
■ Perform resist ance checks. To check resist ance of a com ponent, disconnect
harness leads first .
Pow e r Up
N
L
power swit ch
N
PCBA
L
