Gallagher 3E5260 M6000i/M12000i Energizer User Manual
13
UNDERSTANDING YOUR ENERGIZER CONTROLLER
Current Display
Shows the amount of load on the
energizer / fence zones
Voltage Display
Shows energizer / earth / fence zones voltage
Status LED
Provides quick
indicaon of the
fence status
Zone
Indicators
Displays which
energizer / earth
/ fence zones are
operang and if
they are in alarm
Sengs buons
Change alarm levels and
energizer output voltage
Standby buon
Turns the energizer pulses
on and o
Navigaon Buons
View energizer / earth /
fence zones to see zone
performance
Quickscan
Bargraph
Gives fast visual
indicaon of fence
voltage
Zone Indicaon
Arrow
Highlights which
energizer / earth /
fence zone is being
shown on the main
display
Status LED
Green The energizer and fence are operang normally
Red The energizer has detected a fault. Check the LCD screen to
determine where the problem is.
Flashing Red The energizer output voltage is low.
Quickscan Bargraph
The Quickscan bargraph gives quick visual indicaon of the energizer output voltage.
Each bar illuminated represents approximately 1KV output.
Green Segments Your fence is performing well. No aenon is required.
Yellow Segments Your fence is under some load but is sll delivering an
eecve shock.
Red Segments Your fence is under heavy load and requires maintenance.
