Game ready 500055 - Control Panel Features Overview; Pressure Settings Explained; Pre-Set Program Display Guide

13
High
5-75 mmHg
Medium
5-50 mmHg
Low
5-15 mmHg
No pressure
GS
PRESSURE SETTINGS
CONTROL PANEL
Power (on/off)
Green indicates unit has power
Pressure display
Second tick marks
Temperature display
Temperature knob
Start/pause
Timer on
Decrease time
Timer setting
Increase time
Pressure setting
Alarm silencer
Celsius/Fahrenheit
PRE-SET PROGRAM DISPLAY (For Pre-Programmed Control Units Only)
Program Indicator
Treatment Time
Pressure Display
Low (5-15 mmHg)
Med (5-50 mmHg)
High (5-75 mmHg)
Sleep Time
between Treatments
& Temperature in Use
30/30/ No Pressure
30/30/ Low Pressure
30/30/ Med Pressure
