CONTROL UNIT ORIENTATIONS
YOUR GAME READY SYSTEM
The Control Unit can sit upright (Fig. A) or on one side (Fig. B) to fit on a shelf.
Caution: Do not put the unit on the side where the control panel is upside down. This will
cause the unit to leak water.
Note: The Wrap is comprised of an inner heat exchanger and an outer sleeve. The combi-
nation of sleeve and heat exchanger is referred to throughout this manual as a “Wrap.”
Figure A: Upright
Figure B: Side
