ALERTS
The following table shows the various light signals generated by the
control unit with their meaning and possible operations to be performed.
CONTROL UNIT FEEDBACK
CONTROL UNIT STATUS GREEN LED RED LED SOLUTION
READY FOR COMMANDS
EXECUTION
ON OFF -
WAITING FOR AUTOMATIC
CLOSING
SHORT SHUTDOWN EVERY
3 SECONDS
OFF -
MOTOR UPWARDS
SLOW FLASHING WITH
DUTY CYCLE 50%
OFF -
MOTOR DOWNWARDS
FAST FLASHING WITH
DUTY CYCLE 50%
OFF -
PAUSE TIME PROGRAMMING
SHORT FLASHING EVERY
SECOND
OFF SEE PROCEDURE 5.1
WORKING TIME
PROGRAMMING
ON ON SEE PROCEDURE 5.3
RESET IN PROGRESS
3 CLOSE FLASHINGS
EVERY 3 SECONDS
OFF PUT DIP 5 AND 6 IN OFF
TROUBLESHOOTING
RED LED ERROR SOLVING
1 FLASH CHECK THE STOP BUTTON CONNECTIONS
2 FLASHES
CHECK THE SAFETY DEVICES CONNECTIONS / CHECK SAFETY
ACTIVATION
8 FLASHES
CHECK:
• POWER SUPPLY
• OVERLOAD OUTPUT 12V (TERMINALS 9-3)
• OVERLOAD OUTPUT 24Vac (TERMINALS 11-12)
LED SWITCHES ON STEADILY
WRONG DIPS SETTING, FOLLOW THE BELOW PROCEDURE:
1. SET ALL DIPS IN OFF POSITION
2. WAIT FOR 5 SECONDS
3. SET THE DIPS IN THE DESIRED POSITION FOLLOWING THE
INSTRUCTIONS
