SAFETY DEVICES
The safety of the board are managed via DIP 3 and 4:
SAFETY LOGIC DIP 3
When an obstacle is detected during the way down the move-
ment is reversed until the opening limit switch; It has no effect
on the way up.
OFF
When an obstacle is detected during the way down the opening
movement is inverted for 2 seconds and then it stops. When an
obstacle is detected during the way up the movement is imme-
diately stopped.
ON
TYPE OF SAFETY SELECTION DIP 4
Security input for normally closed contact. OFF
Security input for optoelectronic bar with digital signal.
To be connected as follows: Mass in terminal 3, + 12V DC in
terminal 9, digital signal in terminal 10.
ON
