Garbin 64PL VAP - Technical Specifications and Rating Plate

ELECTRIC VENTILATED OVENS
GB
1.4 - Technical specifications and rating plate
28
DATA PLATE
pict. 1
Cod.
Id. n°
Mod.
Id. n°
KW
10/04/26
IT09120000006460
MADE IN ITALY
Model 25GE/25GL VAP 45GE/45GL VAP 46PE/46PL VAP
Power 3300 W 7000 W 7000 W
Power supply 230V~; 50/60 Hz 400V~ 3N; 50/60 Hz 400V~ 3N ; 50/60 Hz
Electrical connection Type “X” Type “X” Type “X”
Weight 50 kg 60 kg 60 kg
Dimensions (mm) 635 x 770 x 685 965 x 830 x 610 965 x 830 x 610
Capacity N. 5 trays N. 4 trays N. 4 trays
2/3 GN 1/1 GN 600 mm x 400 mm
Distance between trays 75 mm 75 mm 80 mm
Max. food load 6kg. per shelf (food and pan)
Wiring type H07RN-F H07RN-F H07RN-F
3X2.5 mm
2
3x4 mm
2
/5X2.5 mm
2
3x4 mm
2
/5X2.5 mm
2
Water inlet 3/4” G 3/4” G 3/4” G
Water hardness Max 3° F Max 3° F Max 3° F
Water pressure 150-300kPa 150-300kPa 150-300kPa
IP rating IPX0 IPX0 IPX0
Mounting On bench or stand
