TRENCHER TZ S
Use and maintenance instructions – Spare parts Via L.da Vinci,32/B
Rev. 01.2013 - EN (translation of the original instructions)
19
36034 Malo (VI) Italy
T E Z A
TYRES
Studded drive tyres with inner tube
“TRACTOR” 16x6.50-8 4PR
Support tyres with inner tube
15.600x6”PR RIG
CHAIN TRENCH ASSEMBLY
Trench chain with tool holder bars
Length of chain:
standard 32 pins
Main shaft pin and lead pinion
Z 4
Number of digging tools
standard 16 tools
Tool type: slotted and/or needle with tip in tungsten carbide
Mechanical chain tension adjuster
WEIGHTS AND DIMENSIONS
Operating weight with 45 cm trench jib and fuel tank
full
133 kg
For dimensions see
FIG. 5
PERFORMANCE
Trench depth
standard 45 cm
Trench width
Slots: 11 - 13 cm
Needles: 10 - 12 cm
Mixed: 11 - 13 cm
SAFETY DEVICES
Safety bar for chain
Safety device for stopping the engine by releasing the red lever on the handlebar (normally-open micro
configuration)
NOISE AND VIBRATIONS
Sound power Lw(A) 102 [dB(A]
Equivalent sound pressure at operator station
• Engine idling
• Engine at max. revs and chain
Leq(A)
74.0 [dB(A]
88.4 [dB(A]
Vibrations transmitted to operator station with engine idling
• Left hand
• Right hand
A(8)
3.45 [m/s²]
2.39 [m/s²]
Vibrations transmitted to operator station with engine at max.
revs and chain turning
• Left hand
• Right hand
A(8)
14.49 [m/s²]
24.66 [m/s²]
Data collected from no-load tests
TAB. 2 (Technical data)
