Garbin TZ S - Technical Data

TRENCHER TZ S
Use and maintenance instructions – Spare parts Via L.da Vinci,32/B
Rev. 01.2013 - EN (translation of the original instructions)
18
36034 Malo (VI) Italy
T E Z A
MACHINE
ENGINE
Brand HONDA
Type
GX 200
Engine type
Single-cylinder OHV engine with horizontal
shaft, Otto cycle, 4 stroke, cylinder inclined 25°,
forced-air cooling
Stroke x bore mm 68 x 54
Displacement cm
3
196
Compression ratio 8.5:1
Maximum power kW/HP 4.8 kW (6.5 HP) / 3600 rpm
Net power kW/HP 4.1 kW (5.5 HP) / 3600 rpm
Continuous rated power kW/HP
3.3 kW (4.4 HP) / 3000 rpm
3.7 kW (5.0 HP) / 3600 rpm
Max. torque Nm/kgf. 12.4 Nm / 12.6 kgf / 2500 rpm
Ignition
Contact-free transistor
Starting
Pull-start with spring rewind
Tank capacity litres 3.1
Fuel consumption at rated power Litres/hour 1.7 Litres/hour– 3600 rpm
Capacity of oil sump litres 0.6
Overall dimensions (L x W x H) mm 313 x 376 x 346
Dry weight kg 16
TRANSMISSION TO WHEELS
Automatic transmission via jack mechanism
TRANSMISSION TO TOOL
Mechanical transmission to trench chain via belt and gear reducer in an oil bath
Gear reducer SITI
ELECTRICAL SYSTEM
Safety device for stopping the engine by releasing the red lever on the handlebar (normally-open micro
configuration)
3.5- TECHNICAL DATA
TAB. 2 shows the main technical data of the machine.
