TRENCHER TZ S
Use and maintenance instructions – Spare parts Via L.da Vinci,32/B
Rev. 01.2013 - EN (translation of the original instructions)
43
36034 Malo (VI) Italy
T E Z A
MAINTENANCE SHEET
N° 02
WORK POINT
MAIN SHAFT BEARINGS
TYPE OF OPERATION GREASING
EVERY DAY
1) Grease the main shaft bearings using the grease nipple. Pos. 1
2) Record the operation on registration sheet N°02.
TOP VIEW
Pos. 1
MATERIAL DISCHARGE SIDE
LH SIDE
RH SIDE
TOP VIEW
