TRENCHER TZ S
Use and maintenance instructions – Spare parts Via L.da Vinci,32/B
Rev. 01.2013 - EN (translation of the original instructions)
53
36034 Malo (VI) Italy
T E Z A
MAINTENANCE SHEET
N° 07
WORK POINT
OPEN GREASE NIPPLES + LUBRICATE
TYPE OF OPERATION GREASE + LUBRICATE
EVERY DAY
1) Grease all the indicated points (see Fig.).
2) Record the operation on registration sheet N°07.
RH SIDE
LH SIDE
