Gardena 11000 SL automatic User Manual

17
GB
8. Technical Data
Type 11000 SL automatic (Art. 1786) 15000 SL automatic (Art. 1788)
Rated power 550 W 750 W
Max. delivery capacity 11,000 l/h 15,000 l/h
Max. pressure 0.8 bar 0.9 bar
Max. delivery height 8 m 9 m
Max. submersion depth 9 m 9 m
Flat suction down to approx. 1 mm 1 mm
Contaminated water with
particle size of max. 5 mm 5 mm
Power cable 10 m H07 RNF 10 m H07 RNF
Pump connection 38 mm (1 1/2” ) / 25 mm (1” ) graduated nipple,
option GARDENA Water hose Plug-in-system
Min. water level for operation 35 mm 35 mm
Weight approx. 7 kg 7 kg
Max. media temperature 35 °C 35 °C
Mains voltage /
mains frequency 230 V / 50 Hz 230 V / 50 Hz
Cut-in height 185 mm 185 mm
Cut-out height 55 mm 55 mm
Noise level L
WA
1)
48 dB(A) 50 dB(A)
1) Measuring method according to EN 60335-1
The cut-in and cut-out height varies.
The residual water height (flat suction down to approx. 1 mm)
is only reached during manual operation with the swivel feet
8
turned to 1 mm (see 4. Operation).
Cut-in / Cut-out height
m
10
8
6
4
2
0
0 5000 10000 15000
l/h
bar
1.0
0.8
0.6
0.4
0.2
11000 SL automatic
15000 SL automatic
Performance characteristics

Gardena 11000 SL automatic Specifications

General

Max. delivery capacity	11000 l/h
Max. self-priming suction	8 m
Rated power	1100 W
Max. liquid temperature	35 °C
Connection cable type	H07 RNF
Protection class	IPX8
Power Consumption	1100 W
Voltage	230 V
Frequency	50 Hz
Inlet/Outlet	G1
