5. MAINTENANCE
DANGER! Electric shock!
Risk of injury due to electric shock.
v Disconnect Garden Pump from the mains before
carrying out maintenance.
Cleaning the filter [ Fig. M1 ]:
If the filter is dirty it has to be cleaned.
1. Close all shut-off valves, if any, on the suction side.
2. Unscrew and remove cover
6
of the filter chamber.
3. Draw out filter unit vertically upwards.
4. Hold beaker
0
firmly, turn filter
q
anti-clockwise 1
and draw out 2 (bayonet fitting). [ Fig. M2 / M3 ].
5. Clean beaker
0
under running water and clean the
filter
q
e. g. with a soft brush.
6. Refit filter again in reverse order.
Flush through Garden Pump:
The pump must be flushed through after discharging
chlorinated swimming pool water.
1. Pump through lukewarm water (max. 35 °C), possibly
adding a mild cleaning agent (e.g. detergent) until the
pumped water runs clear.
2. Remove residuals according to the waste disposal laws
applicable in your area.
6. TROUBLESHOOTING
DANGER! Electric shock!
Risk of injury due to electric shock.
v Disconnect Garden Pump from the mains before
trouble-shooting.
Free the impeller [ Fig. T1 ]:
An impeller blocked by dirt can be freed again.
v Turn the impeller bolt
w
using a screwdriver.
This will free the blocked impeller.
Cleaning the flow sensor [ Fig. T2 ]:
If the flow sensor is dirty, this may result in spurious error
messages (LED flashes orange).
1. Unscrew both screws
e
.
2. Remove the cover
r
.
3. Undo the screw
t
and detach the clip
z
.
4. Unscrew the cap
u
anticlockwise.
5. Remove the impeller
i
and clean it. Clean the housing
of the flow sensor.
6. Re-fit the impeller
i
with the metal part in the mounting
direction.
7. Screw the cap
u
into place clockwise.
8. Secure the cap
u
by way of the clip
z
using the
screw
t
.
9. First insert the cover
r
at the top and then tighten the
two screws
e
at the bottom.
Problem Possible Cause Remedy
Pump runs, but the suction
action doesn’t take place
Pump sucks in air at a joint. v Seal connections on suction side so
are airtight.
Leaky or damaged suction
hose.
v Check suction line for damage and
seal so is airtight.
The pump was not filled with
the liquid to be pumped.
v Fill the pump (see 3. OPERATION).
The liquid escapes over the
hose which is connected to
the delivery side during the suction
action.
1. Fill the pump again
(see 3. OPERATION).
2. When starting operation hold the
pressure hose approx. 1m vertically
above the pump, until the suction
action has taken place.
Absolutely vacuum-resistant connection is achieved by using GARDENA
Suction Hoses (see point 7. ACCESSORIES).
Leaky screw fitting
6
at the filler
cap
7
.
v Check seal (replace if necessary) and
tighten connection securely (do not
use pliers).
