15
GB
Problem Probable cause Remedy
Pump is running, Feed impeller clogged. ➔ Disconnect plug and clean
but does not deliver.
feed impeller (see 6. Cleaning).
When starting the pump, ➔ Submerge pump deeper
water height falls below the into water.
minimum water level.
Pump doesn’t start or Thermal overload switch has ➔ Disconnect plug and clean
suddenly stops during switched the pump off due feed impeller
operation. to overheating. (see 6. Cleaning).
Observe maximum water temper-
ature of 35 °C.
No power. ➔ Check fuse and electrical
plug and socket connections.
Dirt particles are jammed ➔ Disconnect plug and clean
in the suction base. suction base
(see 6. Cleaning).
Pump runs, but output Suction base is clogged. ➔ Disconnect plug and clean
suddenly decreases. suction base
(see 6. Cleaning).
Attention! Work on electrical parts must only be carried out by
GARDENA Service or an authorised GARDENA repairer.
If you have any problems with your Pump, please contact our Service.
8. Technical Data
Type 6000 (Art. No.1777) Type 6000 (Art. No. 1790)
Mains voltage/mains frequency
220–240 V AC/50 Hz 220–240 V AC/50 Hz
Rated Power 220 W 220 W
Connection cable 10 m; H05-RN-F 10 m; H05-RN-F
Max. delivery capacity 6000 l/h 6000 l/h
Max. pressure/head 0.5 bar/5 m 0.5 bar/5 m
Max. submersion depth 7 m 7 m
Min. depth of water for
switching on
Ca. 330 mm Ca. 350 mm
Min./max. depth for
switching off Ca. 50 mm/95 mm Ca. 65 mm/120 mm
Residual depth of water Empties down to approx. 5 mm 25 mm
Dirty water with
max. particle diameter Ø 5 mm Ø 25 mm
Pump connection 38 mm (1
1
/
2
”)-/25 mm (1”)-stepped connection.
Option GARDENA plug-in connection water hose system for
connecting 13 mm (1/2”)/15 mm (5/8“)/19 mm (3/4”) hoses.
Minimum water level at start-up
50 mm 75 mm
Weight Ca. 3.1 kg Ca. 3.2 kg
Max. water temperature 35 °C 35 °C
Cut-in/Cut-out height: The cut-in and cut-out height varies. The residual water height is
only reached during manual operation (see 4. Operation).
