2. FUNCTION
With the Water Control, the garden can be watered
fully automatically up to 3 times a day (every
8hours) via both outlets. Sprinklers, a sprinkler
system or a drip head watering system can be
used for watering.
The Water Control carries out watering fully auto-
matically according to the set program and can
therefore also be used during holidays. Early in the
morning or late in the evening, evaporation and
therefore water consumption is lowest.
Controls [ Fig. F1 ]:
The watering programme is easily entered using the
controls.
Control Function
1
Man. button For switching the water throughput
on or off manually.
2
OK button
Applies the values set with the ▼-▲
buttons.
3
Menu button Changes to the next programme
level.
4
▼-▲-buttons
(V1 / V2)
Change the adjustable values in
each (V1 / V2) level / selection of outlet
(V1 / V2) in Level 1.
Display levels:
The 6 display levels can be selected one after the
other by pressing the Menu key.
• Level 1: Normal display
• Level 2: Current time and day of the week
• Level 3: Watering start time
• Level 4: Watering duration
• Level 5: Watering frequency
• Level 6: Switch programme on or off /
Deactivate sensor
The display level can be changed at any time by
pressing the Menu button. All programme data
changed up to this time and confirmed with the
OK button is saved. If data is changed during
programmed irrigation and confirmed with the
OK button then the valve is closed.
Display messages [ Fig. F2 ]:
Display Display
5
Weekdays
Mo
,
Tu
…
Current weekday
, or pro-
grammed watering days
.
6
Time Current time of day (flashes when
in input mode).
7
am / pm Display for 12-hour clock
(e. g. in USA, Canada).
8
Start Watering start time (flashes when
in input mode).
9
Run Time Watering duration (flashes when
in input mode).
0
8h, 12h, 24h,
2nd, 3rd, 7th
Watering cycle (with
activated).
Every 8 / 12 / 24 hours;
every 2nd / 3rd / 7th day.
q
Prog
ON / OFF Watering programme on (ON) /
off (
OFF).
w
Direct sensor
control
Watering is automatically controlled
between 20:00 and 06:00 via the
Soil Moisture Sensor.
e
Sensor 1 / 2
dry / wet
Dry sensor dry:
watering is carried out.
Wet sensor wet:
watering is not carried out.
r
Valve
ï
V1 /
Valve V2
ð
The arrow indicates the selected
valve:
– displayed
: the valve is connected
– flashing
: the valve is open
t
Battery
Indicates 5 battery levels:
3 bars: Battery fully charged
2 bars: Battery half full
1 bar : Battery low
0 bar : Battery almost flat
Frame is
flashing: Battery flat
If the battery frame is flashing, the valve is no longer
opened. A valve opened by the programme
will also close again if the battery is flat.
The battery display is reset when the battery is
changed.
15
EN
