4
Figure 1: Front View
The camera provides the following connections for external
devices: Mini USB port and SD card slot etc. (Figure 2).
IR LEDs
Lock
Hole
Optical
Lens
PIR
Lens
Light
Sensor
Indicator
Lock
Buckle
Side PIR
Motion
Sensor
