Part 1382606 Rev 2 (12/07) Page 5
INSTALLATION
Uncrating
Upon arrival, inspect Filter Quick carefully for concealed
damage. Immediately report any damage to the delivery
freight line. Claims for shipping damage must be lled within
15 days after receipt of merchandise.
Proper installation is essential to ecient trouble-free
operation, any alteration of the equipment voids the
warranty.
Rating Plate
When corresponding with the factory or your local
authorized factory service center regarding service problems
or replacement parts, be sure to refer to the particular unit
by the correct model number (including the prex and sux
letters and numbers) and the warranty serial number. The
rating plate axed to the unit contains this information.
We suggest installation, maintenance and repairs should be
performed by your local authorized service agency listed in
your information manual pamphlet.
In the event you have any questions concerning the
installation, use, care or service of the product, write or call
our Product Service Department.
This product must be installed by professional personnel as
specied. Garland/U.S. Range products are not approved or
authorized for home or residential use, but are intended for
commercial applications only. Garland / U.S. Range will not
provide service, warranty, maintenance or support of any
kind other than in commercial applications.
Legs
Raise front of unit and block. Do not lay unit on it’s back.
Position square leg insert into font leg retainer opening and
tap up until it seats at collar ange. Repeat at rear of unit
using round leg insert, making sure all four legs are adjusted
to same height. Legs can be adjusted to overcome an uneven
oor
Assembly of Filter Quick in a Battery
All heavy duty batteries equipment is aligned and tted at
the factory, from left to right and must installed in this order.
There is a diagram provided with every heavy duty battery.
A. All such units should be placed in their respective battery
position. Detach valve panels and, to prevent damage,
remove them from the area where the battery is being
assembled.
B. Level each unit by adjusting the 6” legs, or where legs are
not used, adjust level with shims. Check for level across
front and back tops and on the burner box sides, using a
spirit level. Readjust legs, if required.
C. Connect units together by mating the unions at each
end of the manifold. (Adjoining units must have
matching unions, unless the union parts are of the same
specication, a leakproof connection cannot be assured).
Hand tighten unions at this point.
D. The units should be fastened at the rear by inserting 5/16”
bolts through the holes provided at the rear of the burner
box sides. Install washer and nut and hand tighten. Be
sure of proper unit alignment in the battery before nal
tightening of these bolts or unions. Improper tightening
will cause “fanning” or “bowing” of batteried units.
Assembly of Return Lines
(Refer to Fig. 1)
From the “Tee” on the lter and the Fryer interconnect as
follows:
A. On the left side of the “Tee” install item 4 (1/2 pipe 2-1/2”
long) and the male half of the union item 5. Use Teon
tape on the threads.
B. On the right side of the “Tee” install item 7 (1/2 pipe 12”
long) and the female half of the union item 5. Use Teon
tape on the threads.
C. On the end units of the Filter/Fryer Battery use a pipe
plug on the open ends of the “Tee”. Use Teon tape on the
threads.
Assembly of Drain Tubes
(Refer to Fig. 1,2,3)
NOTE: Drain tube assembly is to be done after units are
batteried.
1. Install close nipple 13 in ball valve.
2. Slip gasket 14 over close nipple.
3. Place drain tube 1 or 8 (see special note) over close
nipple.
4. Install washer retainer 15 and nut retainer 16 and tighten
securely.
5. Install gasket 12 and cover 13 as shown securing with two
wing nuts.
