Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 19
No Description
Part No
Page No
208V 240V
1 Fuse holder 30Z0231 30Z0231 9
1A Fuse 10 amp 30Z0217 30Z0217 9
2 Fuse holder 30Z0231 30Z0231 9
2A Fuse 10 amp 30Z0217 30Z0217 9
3 Fuse holder 30Z0285 30Z0285 9
3A Fuse 1 amp 30Z0957 30Z0957 9
4 Fuse holder 30Z1178 30Z1178 9
4A Fuse 20 amp 30Z1177 30Z1177 9
5 Fuse holder 30Z1178 30Z1178 9
5A Fuse 20 amp 30Z1177 30Z1177 9
6 Electrical supply terminal block 31Z0149 31Z0149 9/18
7 Filter ( Heater circuit ) 30Z0997 30Z0997 9
8 Filter ( Microwave circuit ) 30Z0997 30Z0997 9
9 Door spring Modification Kit
A
10C0177 10C0177 9/10
Door spring( Long ) 40C1141 40C1141 9/10
10 Door arm stop assembly
C
11C0279 11C0279 9/10
11 Microswitch ( Primary ) 30Z0240 30Z0240 9
12 Door hinge assembly ( LH ) 11C0167 11C0167 9/17
13 Door arm assembly 11C0300 11C0300 9/10
14 Microswitch ( Monitor ) 30Z0240 30Z0240 9
16 Door hinge assembly ( RH ) 11C0166 11C0166 10/17
17 Microswitch ( Secondary ) 30Z0240 30Z0240 10
20 Steam pipe S/S 790046 790046 10
21 Steam vent guard 790061 790061 10
22 Temperature sensor 50E123 50E123 10
23 Magnetron 30Z1171 30Z1171 11
24 Resistor 470 R 30Z0283 30Z0283 11
25 HT diode 11C0266 11C0266 11
26
Capacitor 0.88μf (2300V)
D
30Z0861 30Z0861 11
Capacitor 0.88μf (2500V) Kit 10C0172 10C0172 11
27 Transformer ( Multi-tap )
E
30Z1230 30Z1230 11
28 Twin blower motor 30Z1145 30Z1067 11
29 On/Off Switch 30Z0503 30Z0503 15
30 Control Panel Assembly (Except Tim Hortons) 11C0379 11C0379 15
Control Panel Assembly US Tim Hortons 11C0412 11C0412 16
Control Panel Assy. French C. Tim Hortons 11C0413 11C0413 16
Control Panel Assy. UnBranded Tim Hortons 11C0414 11C0414 16
PRINCIPAL COMPONENTS: Part Number Identification Chart 1
Note A: Ovens before June 2003
Note C: For ovens later than May 2005 See Appendix 7
Note D: This Capacitor is replaced with 30Z1251 0.88μf 2500V and 2 x 88mm clips 30Z0521
included in a service kit Part No. 10C0172
Note E: All transformers are now replaced by the Multi-tap type Part No. 30Z1230
