Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 21
PRINCIPAL COMPONENTS: Part Number Identification Chart 3
No Description
Part No
Page No
208V 240V
Door Assembly Garland 11C0336 11C0336 13
Door Assembly Tim Hortons 11C0380 11C0380 13
Door Assembly Unbranded 11C0418 11C0418 13
94 Hot Air Motor Resistor Assy N/A 11C0341 12
95 Diode assy with leads 11M0417 11M0417 10
96 Side Panel Left Side 790002 790002 14
97 Side Panel Right Side 790003 790003 14
98 Top Panel 790005 790005 14
99 Foot 32Z1052 32Z1052 14
100 Wire Shelf 40C1011 40C1011 14
101 Crumb Tray RBR290X02 RBR290X02 14
102 Hot Air Motor Impellor 10C0236 10C0236 14
104 Twin Blower Resistor Assy N/A 11C0477 12
106 Flat Washer S/S M5 x 20 104036 104036 13
107 Nylon Washer 104250 104250 13
108 Spring Washer 31Z5005 31Z5005 13
109 Flat Washer S/S M6 x 20 104054 104054 13
110 Door Spacer Kit 10C0171 10C0171 28
111 Rear Outer Panel 40C0951 40C0951 14
112 Internal Filter LHS 40C0962 40C0962 9
113 Internal Filter RHS 40C1080 40C1080 10
114 Side Bumper RMC6104 RMC6104 14
115 Shelf Support Tim Hortons 10C0174 10C0174 14
116 Air Filter Panel ( removable ) 40C0868 40C0868 14
117 Nut M4 S/S (Door Handle) 31Z4015 31Z4015 13
118 Microswitch support bracket 40C0851 40C0851 9/10
119 Push fit bumper ( rear panel ) 31Z1187 31Z1187 14
121 Roof Corner Cap n/a 40C1113 14
122 LH Front pillar n/a 40C1184 14
123 RH Front pillar n/a 40C1185 14
124 Shelf support fixing bolt 80T7133 80T7133 15
125 PCB standoff 2243033 2243033 15
126 Door arm stop assembly 11C0480 11C0480 Appendix 7
127 Adj. Microswitch support bracket 40C1233 40C1233 Appendix 7
93
93
93
