Garland Mealstream CTM3 User Manual

Mealstream Ovens Pt. No. 32Z3403 Issue 16
Page 23
Test for microwave leakage at all points marked with a
• Readings must be below 4mW/cm². If a level greater that 4mW/cm² is observed,
this should be reported to Garland Service Division immediately.
• In any case, notes should be kept of the leakage that is observed. In terms of level and
position on the oven. This should be kept with the service documentation.
Control Panel - Figure 2
Door Perimeter - Figure 2
Rear and Side Covers - Figure 1, 3 & 4
Left & right Side Air Filters. - Figure 3 & 4
Fig. 1
Fig. 3
Fig. 4
Fig. 2
PROCEDURE FOR MICROWAVE LEAKAGE TEST (2)
