Garland S680 SERIES Installation And Service Manual

Part # P152 Rev 1 (01/13/10) Page 29
MODEL
Phase grouping Loading Chart
SU686RC STD NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 19.3 9.2 4.6 5.5 40.00 20.00 23.91 83.91 L2 Top 3 415V 3N~ 19.3 9.2 4.6 5.5 38.33 19.17 22.92 80.42 L3 Oven 380V 3N~ 17.66 8.42 4.21 5.03 38.26 19.13 22.87 80.26
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top2 400V 3N~ 26.3 9.2 10.1 7.0 40.00 43.91 30.43 114.35 L2 Top 3, Oven 415V 3N~ 26.3 9.2 10.1 7.0 38.33 42.08 29.17 109.58 L3 Salamander 380V 3N~ 24.06 8.42 9.24 6.40 38.26 42.00 29.11 109.38
SU686RC-1L SU686RC- 1C SU686RC-12L
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 18.05 7.95 4.6 5.5 34.57 20.00 23.91 78.48 L2 Top 3 415V 3N~ 18.05 7.95 4.6 5.5 33.13 19.17 22.92 75.21 L3 Oven 380V 3N~ 16.51 7.27 4.21 5.03 33.06 19.13 22.87 75.07
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 25.05 7.95 10.1 7.0 34.57 43.91 30.43 108.91 L2 Top 3, Oven 415V 3N~ 25.05 7.95 10.1 7.0 33.13 42.08 29.17 104.38 L3 Salamander 380V 3N~ 22.92 7.27 9.24 6.40 33.06 42.00 29.11 104.18
SU686RC-1R SU686RC- 12R
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 3 400V 3N~ 18.05 7.95 4.6 5.5 34.57 20.00 23.91 78.48 L2 Top 2 415V 3N~ 18.05 7.95 4.6 5.5 33.13 19.17 22.92 75.21 L3 Oven 380V 3N~ 16.51 7.27 4.21 5.03 33.06 19.13 22.87 75.07
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 3 400V 3N~ 25.05 7.95 10.1 7.0 34.57 43.91 30.43 108.91 L2 Top 2, Oven 415V 3N~ 25.05 7.95 10.1 7.0 33.13 42.08 29.17 104.38 L3 Salamander 380V 3N~ 22.92 7.27 9.24 6.40 33.06 42.00 29.11 104.18
SU686RC-2L SU686RC- 1C-12L SU686RC-24L
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 16.8 6.7 4.6 5.50 29.13 20.00 23.91 73.04 L2 Top 3 415V 3N~ 16.8 6.7 4.6 5.50 27.92 19.17 22.92 70.00 L3 Oven 380V 3N~ 15.37 6.13 4.21 5.03 27.86 19.13 22.87 69.87
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 23.8 6.7 10.1 7.0 29.13 43.91 30.43 103.48 L2 Top 3, Oven 415V 3N~ 23.8 6.7 10.1 7.0 27.92 42.08 29.17 99.17 L3 Salamander 380V 3N~ 21.78 6.13 9.24 6.40 27.86 42.00 29.11 98.98
SU686RC-1R-12L SU686RC-1L-12R
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 3 400V 3N~ 16.8 6.7 4.6 5.50 29.13 20.00 23.91 73.04 L2 Top 2 415V 3N~ 16.8 6.7 4.6 5.50 27.92 19.17 22.92 70.00 L3 Oven 380V 3N~ 15.37 6.13 4.21 5.03 27.86 19.13 22.87 69.87
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 3 400V 3N~ 23.8 6.7 10.1 7.0 29.13 43.91 30.43 103.48 L2 Top 2, Oven 415V 3N~ 23.8 6.7 10.1 7.0 27.92 42.08 29.17 99.17 L3 Salamander 380V 3N~ 21.78 6.13 9.24 6.40 27.86 42.00 29.11 98.98
SU686RC-2R SU686RC- 1C-12R SU686RC-24R
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 2, Top 3 400V 3N~ 16.8 6.7 4.6 5.50 29.13 20.00 23.91 73.04 L2 Top 1 415V 3N~ 16.8 6.7 4.6 5.50 27.92 19.17 22.92 70.00 L3 Oven 380V 3N~ 15.37 6.13 4.21 5.03 27.86 19.13 22.87 69.87
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 2, Top 3 400V 3N~ 23.8 6.7 10.1 7.0 29.13 43.91 30.43 103.48 L2 Top 1, Oven 415V 3N~ 23.8 6.7 10.1 7.0 27.92 38.50 29.17 99.17 L3 Salamander 380V 3N~ 21.78 6.13 9.24 6.40 27.86 42.00 29.11 98.98
SU686RC~2L~12R SU686RC~1L~124R SU686RC~2R~12L SU686RC~1R~24L SU686RC~36
NO SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 2 400V 3N~ 15.55 6.7 3.35 5.50 29.13 14.57 23.91 67.61 L2 Top 3 415V 3N~ 15.55 6.7 3.35 5.50 27.92 13.96 22.92 64.79 L3 Oven 380V 3N~ 14.23 6.13 3.07 5.03 27.86 13.93 22.87 64.67
WITH SALAMANDER export (wye) load voltage total kW kW L1 kW L2 kW L3 A L1 A L2 A L3 A 1 phase
L1 Top 1, Top 3 400V 3N~ 22.55 6.7 8.85 7.0 29.13 38.48 30.43 98.04 L2 Top 2, Oven 415V 3N~ 22.55 6.7 8.85 7.0 27.92 33.74 29.17 93.96 L3 Salamander 380V 3N~ 20.63 6.13 8.10 6.40 27.86 36.81 29.11 93.78
