Specifications
Temperature range From -20° to 55°C (from -4° to 131°F)
Material Polycarbonate
Water rating IEC 60529 IPX65
1
Dimensions (W × H × D) 229 × 106 × 41 mm (9 × 4
3
/
16
× 1
5
/
8
in.)
Weight 400 g (14.08 oz.)
Input voltage From 0 to 16 Vdc
NMEA 2000 LEN @ 9 Vdc 0
Fuse 50 A
Compass-safe distance 5 cm (2 in.)
Max. power usage at 12 Vdc 50 A
Typical current draw at 12 Vdc Approximately 65 mA
NMEA 2000 PGN Information
Transmit and Receive
PGN Description
127501 Binary switch
127502 Binary switch
127505 Fluid level
127508 Battery status
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating.
