Garmin Boat Switch - Garmin Boat Switch LED Codes; Display Codes

Garmin Boat Switch LED Codes
The color and blink sequence of the status LEDs on the Garmin Boat Switch device indicate its operational
status and the status of in-use and overridden switches.
LED Label LED Color LED State Status
Green Slow blinking The Garmin Boat Switch device is connected to power.
COM Green Rapid blinking
The Garmin Boat Switch device is connected to the NMEA 2000
network. The blink interval changes based on the amount of data being
transferred.
COM Red Solid
The Garmin Boat Switch is not connected to the NMEA 2000 network.
Indicates a connection or communication failure with the NMEA 2000
network.
1-31 Green Solid The designated channel switch is active.
1-31 Green Slow blinking The designated channel switch is selected.
1-31 Green Rapid blinking The designated channel switch is manually activated.
1-31 Red Rapid blinking The designated channel switch is manually deactivated.
1-31 Red Solid The designated channel switch has tripped a software fuse.
Display Codes
The characters shown on the screen of the Garmin Boat Switch device indicate its operational status.
Display Code Status
SEL The Garmin Boat Switch device is in manual selection mode.
CUA The Garmin Boat Switch device is operating normally.
C01-C29 The designated channel switch is selected.
ON The designated channel switch is manually activated.
OFF The designated channel switch is manually deactivated.
ddd The Garmin Boat Switch device is exiting manual selection mode.
