Garmin G1000 Cockpit Reference Guide for the Cessna Caravan
190-00748-00 Rev. C
15
AFCS
Flight
Instruments EIS
Nav/Com/
XPDR/Audio AFCS GPS Nav
Flight
Planning Procedures
Hazard
Avoidance
Additional
Features
Abnormal
Operation
Annun/
Alerts Appendix Index
LATERAL MODES
Lateral Mode Description Control Annunciation
Roll Hold
Holds the current aircraft roll
attitude or rolls the wings level,
depending on the commanded
bank angle
(default) ROL
Low Bank
Limits the maximum commanded
roll angle
BANK
Key
*
Heading Select
Captures and tracks the Selected
Heading
HDG
Key
HDG
Navigation, GPS
Captures and tracks the selected
navigation source (GPS, VOR,
LOC)
NAV
Key
GPS
Navigation, VOR Enroute
Capture/Track
VOR
Navigation, LOC
Capture/Track
(No Glideslope)
LOC
Backcourse Capture/
Track
Captures and tracks a localizer
signal for backcourse approaches
BC Key BC
Approach, GPS
Captures and tracks the selected
navigation source (GPS, VOR,
LOC)
APR Key
GPS
Approach, VOR Capture/
Track
VAPP
Approach, LOC Capture/
Track
(Glideslope Mode
automatically armed)
LOC
Takeoff (on ground)
Disengages the autopilot and
commands a constant pitch angle
and wings level on the ground in
preparation for takeoff
GA
Switch
TO
Go Around (in air)
Disengages the autopilot and
commands a constant pitch angle
and wings level while in the air
GA
* No annunciation appears in the AFCS Status Box. The acceptable bank angle range is indicated in
green along the Roll Scale of the Attitude Indicator.
The GFC 700 limits turn rate to 3 degrees per second (standard rate turn).
