Fuel & Engine Indicating System
190-01717-10 Rev. H Pilot’s Guide 8-43
Electrical
8.14 Electrical Gauges
APPLICABLE TO PISTON &
TURBINE AIRCRAFT
To accommodate more complex electrical
systems, electrical gauges allow up to six
parameters to display on three dedicated rows.
These may include: • main generator • standby
alternator • multiple buses • batteries
Markings and gauge titles are dependent upon
configuration.
