Garmin GTX 3X5 User Manual

190-01499-02 GTX 3X5 Transponder TSO Installation Manual
Rev. 4 Page C-8
C.7 Traffic Sensors (GTX 345 Only)
Table C-7 Traffic Sensors
Notes:
[1] Configure the listed function(s) with the appropriate ARINC 429 channel based on the specific installation.
[2] ARINC 429 output from GTX 345 to GTS 800 is not required, but is required for all other GTS 8XX units.
Manufacturer Model
Configuration
Parameter
I/O
(To/From GTX)
Interfacing Equipment Configuration
GTX 345
Configuration
Setting
Notes
Avidyne
RYAN TAS
600 (9900BX)
RS-232 Input/Output N/A TRAFFIC FMT 4
Configuration setting available on
RS-232 Channel 4 only
Garmin GTS 8XX ARINC 429
Input
Traffic Display Destination (Primary TX)
[1]
TRAFFIC 1
(Speed - HIGH)
Output [2]
Transponder 1 Communication (Primary
RX)
[1]
FORMAT 4
(Speed - HIGH)
Data format includes Garmin TAS.
Pressure Altitude Source (Primary RX);
Magnetic Heading Source (Primary RX);
GPS Position/Velocity/Time Source
(Primary RX);
Transponder 1 Communication (Primary
RX)
[1]
FORMAT 5
(Speed - HIGH)
Data format includes Garmin TAS as well
as Garmin concentrator; required for
G1000.
N/A
Transponder 1 Communication (Primary
TX) [1]
(Speed - LOW)
N/A
This interface is required for GTS 8xx
installations, even though it does not
correspond to physical interface/wiring
(configure for an unused ARINC 429
output port on the GTS 8XX).
Honeywell
(Bendix/King
KTA 870/810
KMH 880/820
KTA 970/910
KMH 980/920
ARINC 429 Input
Controller - Discrete
Intruder File Protocol - ARINC 735
TRAFFIC 5
(Speed - HIGH)
L3 Comm
SKY 497
SKY 899
ARINC 429 Input N/A
TRAFFIC 2
(Speed - HIGH)
