190-01499-02 GTX 3X5 Transponder TSO Installation Manual
Rev. 4 Page D-11
NOTES
Figure D-6 Single/Dual GTX 335 - Single GTN 6XX/7XX Interconnect
DASHED AREAS INDICATE ADDITIONAL INTERCONNECTS FOR DUAL INSTALLATION AND ARE NOT
REQUIRED FOR SINGLE INSTALLATION.
AUDIO INHIBIT I/O PIN IS CONFIGURABLE. REFER TO PIN CONFIGURATION SECTION FOR DETAILS.
GTN 6XX/7XX
GTX 335
27
8
46
29RS-232 IN 3
RS-232 OUT 3 7
50RS-232 GND 3
RS-232 OUT 1
RS-232 IN 1
SIGNAL GROUND
s
P1001
TAWS AUDIO ACTIVE3537AUDIO INHIBIT
GTX 335
29RS-232 IN 3
RS-232 OUT 3 7
50RS-232 GND 3
37AUDIO INHIBIT
7
RS-232 IN 2
RS-232 OUT 2
26
45 RS-232 GND 2
s
P3251
P3251
(GTN 6XX/7XX TAWS
UNITS ONLY)
s
s
2
2
1
2
