Introduction: iQue Components
1.3
Chapter 1 Introduction
Left Side View
REC
Button
Thumb
Wheel
ESC
Button
Top View
Stylus
External
Antenna
Connector
IR Port
Headphones
Jack
GPS Antenna
(in down position)
Expansion
Card Slot
Bottom View
Interface Connector
AC Charger
Connector
Slots for leather
flip cover
Locating Side, Top, Bottom and Back Panel Components
• REC Button: Press to activate the digital voice recorder and speak into the microphone like a tape recorder to record notes
or memos.
• Thumb Wheel: Rotate up or down to scroll or push in to select items and run applications.
• ESC Button: Returns to previous display.
• Stylus: Use to tap icons and buttons on the screen or enter data on the Graffiti® 2 writing area. To use the stylus, remove it
from the side channel and hold it as you would a pen or pencil.
• External Antenna Connector: accepts a Garmin GA27C low profile remote antenna.
• IR Port: Uses infrared technology to transmit and receive data to and from other iQue or Palm OS
®
handhelds and to
perform HotSync
®
operations. See “Beaming Information” in Chapter 8 and “IR HotSync Operations” in Chapter 9 for more
information.
• Expansion Card Slot: Accepts SD expansion cards for flexible memory storage and additional software.
• Headphones Jack: Plug in headphones for listening to MP3 audio files, digital voice recordings, or navigation guidance.
• AC Charger Connector: Connects to the AC wall charger for battery recharge only.
• Interface Connector: Connects your handheld to the cradle, which in turn connects to a USB port on your computer and to
the wall current through the AC adapter. Connecting to the cradle allows you to recharge your iQue handheld and update the
information between your handheld and the computer using HotSync
®
technology.
NOTE: Before using the iQue 3600 for the first time, the battery must be charged for three hours. See the Setup Guide,
located with the Setup CD, for more information.
