GarrettCom Magnum CS14 Series User Manual

CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
22
www GarrettCom com ..
The front side of the unit has two twisted-pair 10/100Mb switch ports and one 10 or 100Mb
fiber port. Both the RJ-45 ports of the CS14 and CSN14 Series Converter switches support
auto-cross (MDIX) operation performing the auto-cross function under auto-negotiation
mode only. The 10Mb fiber (CSN14 models) are factory configured at Half-duplex, and
100Mb (CS14 models) are factory configured at Full-Duplex.
Two sets of LEDs to indicating the operating status of ports are mounted on the
top and front (for extra viewing advantage while rack-mounted). For each port, there are
Link and Activity (LK/ACT) LED’s on the top indicating that the media cables are
connected correctly and showing, by blinking, when there is traffic. The LK/ACT LED’s
are repeated on the front as LA1 (port 1), LA2 (port 2), and LA3 (port 3). There is a power
(PWR) indicator on the front of the unit to validate that the unit is turned ON.
The single fiber port on the CSN14’s is multi-mode with an ST connector and ,
on the CS14’s, it is an SC, ST or small form-factor connector (MTRJ multi mode or LC
Fi
g
2.2c
