GarrettCom Magnum CS14 Series User Manual

CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
44
www GarrettCom com ..
The Magnum CS14 and CSN14 models with “HR” have 24VDC power, and have
the DIN-Rail-MC2 bracket included and assembled with the MC unit at the factory.
3.5 Power Requirements, Power Supply Types for CS14 and CSN14 Series Switches
Magnum CS14 and CSN14 Series Switches are power-efficient and can work with an
external AC power supply. Magnum CS14 and CSN14 Series require a nominal 12VDC
input version. The extended temperature (H and P) versions are used for heavy duty
industrial applications.
The 12V DC power input has a plug of 2.5mm, center +ve , with 6 ft. cord. All the AC
power supply info detail is provided in Technical Specifications Section 1.1.
The CS14 and CSN14 Series are designed to be used with UL listed Class II
power supplies. The CS14P/S14H converter switches provide reliable operation, withstand
