optional; it connects to the CS14H chassis. Ensure that each lead is securely tightened from
the top, as shown here.
NOTE: Always use a voltmeter to measure the voltage of the incoming power supply
and figure out the +ve potential lead or -ve potential lead. The more +ve potential lead
will connect to the post labeled “+ve” and the rest to the “-ve”.
The GND can be hooked up at the last.
When power is applied, the green PWR LED will illuminate.
3.8 Connecting Ethernet Media
The Magnum CS14 and CSN14 Series Converter Switch can be connected to two
media types i.e. fiber and copper (RJ-45) types, runt at 100BASE-TX, 10BASE-T and
100BASE-FX, or 10BASE-FL. CAT 5 cables should be used when making 100BASE-TX
connections. When the ports are used as 10BASE-T ports, CAT 3 may be used. In either
case, the maximum distance for unshielded twisted pair cabling is 100 meters (328 ft). For
