CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
41
www GarrettCom com ..
In a typical installation, the MC14-TRAY, 19” rack-mount tray will hold a few (three to
eight) CS14 and CSN14 Series Converter Switches, with their power supplies plugged into
power strips (not included) in the rear area of the tray. Metal mounting screws in the
bottom-front hold the Converter Switches firmly in place. The beveled-top edge of the units
permits the LEDs of each unit to be viewed for operational status, even when the units are
very close together.
3.3 MC14-TR+PS9 and MC14-TR+PS9X2 for Rack Mounting Media Converters
The MC14-TR+ PS9 and MC14-TR+PS9X2 are other options for rack mounting the mix of
Magnum 10Mbps and 100Mbps Converter Switches and Media Converters together in a
19” rack-mount tray. These models come with built-in common universal AC power supply
rated at 55 watts at 50°C ambient, 12VDC output, and supporting up to 10 Switches for
MC14-TR+PS9 and 16 units CS14 and CSN14 Series for MC14-TR+PS9X2. The MC14-
