CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
42
www GarrettCom com
..
TR+PS9X2 Model has two groups of eight units per power supply. The power supplies
have auto-ranging AC input for use
worldwide.
The side-view below is an example
of an installation of the model
MC14-TR+PS9, 19” rack-mount
tray, holding a few CS14 and
CSN14, FT14 and 14E Media
Converters, each with their power
input plugged into the built-in
common AC power supply in the rear
area of the tray. (PS units that come with the MC’s are not used).
