CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
46
www GarrettCom com
..
3.6 Powering the CS14H, CSN14H and CS14P, CSN14P (DC internal) with 12V, 24V
or –48VDC power input
Each Magnum CS14H/CS14P-Series
is reliably equipped with an internal DC power
supply, and has built-in screw terminals for
secure attachment of the power leads. Three
models support a range of power input types.
The three model choices are for use with
12VDC, 24VDC or -48VDC power. DC power
input may be chosen for high-availability.
The extended temperature capability of the DC-powered CS14P’s can go
temperature uncontrolled environments, rated at –40`C to +75`C. If indoors, the DC jack is
also present and optionally can be used with an external AC power supply.
