CS14, CSN14 Series Converter Switches Installation and User Guide (02/06)
61
www GarrettCom com
..
located underneath the fiber port. The Fiber port with 10Mb is being set at Half-Duplex,
and the 100Mb being set at Full-Duplex as default from the factory. The port can be set at
the required mode, by sliding the manual switch position to “F” or “H”.
4.4 Dual LEDs, Front-panel and side-panel (Magnum CS14 and CSN14)
LED
Description
PWR Illuminates GREEN to indicate power applied.
LK/ ACT Steady ON for LINK w/no traffic, blinking for activity per port. LINK will turn
off in the event connectivity is lost between the ends of the twisted pair segment
or a loss of power occurs in the unit or remote device. The Link ports are also
represented by LA1, LA2, LA3. (Steady On or steady Off indicates no Receive
Activity).
10/100 Steady ON for 100Mb speed, OFF for 10Mb speed per port
F/H Steady ON for Full duplex mode, OFF for half duplex per port
