Installation Instructions
UNPACK THE AIR CONDITIONER
Remove packaging materials
• Remove and dispose of/recycle packaging materials. Remove tape and glue residue
from surfaces before turning on the air conditioner. Rub a small amount of liquid dish
soap over the adhesive with your fngers. Wipe with warm water and dry.
• Do not use sharp instruments, rubbing alcohol, fammable fuids, or abrasive cleaners to
remove tape or glue. These products can damage the surface of your air conditioner.
• Handle the air conditioner gently.
INSTALL PORTABLE AIR CONDITIONER
Install exhaust hose and adaptor
1. Roll the air conditioner to selected location, see “Location Requirements.”
2. Insert the hose adapter into the slot on the back of the air conditioner.
3. Slide down to lock the hose into place.
A. Evaporator Air Intake
B. Hose Adaptor
C. Flexible Exhaust Hose
D. Condenser Air Intake
4. Attach the window exhaust adapter to the fexible exhaust hose. Turn clockwise until
securely locked into place.
A. Flexible Exhaust Hose
B. Window Exhaust Adapter
WARNING: Excessive Weight Hazard
• Use two or more people to move and install the air
conditioner. Failure to do so can result in back or other injury.
!
A
B
D
C
A
B
