Model No. 043-6127-2/043-6128-0/043-6129-8/043-6130-2/043-6131-0/043-5499-2 | Contact us: 1-800-268-6591
Installation Instructions
WINDOW INSTALLATION
Window slider kit has been designed to ft most standard vertical and horizontal window
applications. Roll the air conditioner to selected location, see “Location Requirements.”
1. Insert the windows exhaust adaptor into the slot on the window slider kit.
A. Window Slider Kit
B. Window Exhaust Adaptor
2. Using 2 of the bolts, washers and nuts (provided), attach the rain cover to the window
slider kit for either the vertical or horizontal installation.
NOTES:
• The holes in the window slider kit are positioned for attaching the rain cover
for vertical or horizontal installation.
• Insert the other 2 bolts, washers and nuts (provided) into the unused holes
in the window slider kit to keep moisture from leaking through the window
slider kit.
A
B
