Gate Titan Quick Start Guide

61 TITAN Troubleshooting
Under Voltage Protection 3 (UVP3)
Protection against over-discharge of the battery. Battery protection
was activated immediately aer connecting the battery.
What happened:
1. Number of cells is dierent than their number set in GCS
2. The battery is discharged
What to do:
1. Set the same number of cells in GCS as in the battery
2. Charge the battery
Motor Disc (MOTOR DISC)
TITAN did not detect the motor.
What happened:
1. Motor is not connected
2. Brushes are worn out
3. Motor is damaged
3
4

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
