Gate Titan Quick Start Guide

62
What to do:
1. Check wiring and motor connectors
2. Connect the motor
3. Replace brushes
4. Replace the motor
Gear Not Detected (GND)
TITAN did not detect the sector gear.
What happened:
1. Too high sector gear shimming
2. Sector gear sensor is dirty
3. Sector gear sensor is damaged
4. Sector gear is jammed
5. Motor is damaged
What to do:
1. Remove shims under the sector gear
1

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
