Gate WARFET - Troubleshooting Guide; Troubleshooting for Wiring Modes; Troubleshooting Hardwired Installation

Ţ HARDWIRED INSTALATION Ţ
After a trigger action, the LED
indicator glows yellow. Even
though the motor is connected, the
AEG does not fire.
After connecting the motor to the
Power Module, the AEG starts
firing immediately.
After connecting the motor to the
Power Module, the AEG starts
firing immediately.
The WARFET does not react
to any trigger action. The AEG
does not fire.
After a trigger action, the LED
indicator glows yellow. Even
though the motor is connected, the
AEG does not fire.
No contact with the motor.
The motor wires are broken.
The motor windings are broken.
A short-circuit in the
assembly.
switch
The WARFET is set on the
Stock Wiring mode.
The WARFET is set on the
Stock Wiring mode.
No contact with the Signal Socket.
No contact with the switch
assembly.
A short-circuit or break in the
trigger wire (from the switch
assembly).
The WARFET is set on the
Modified Wiring mode.
Clean the Power Module connector.
Check and repair the motor wires.
Repair the motor or replace it with
a new one.
Check and repair the
assembly.
switch
Reprogram the WARFET to
the Modified Wiring mode.
Reprogram the WARFET to
the Modified Wiring mode.
Clean the Power Module Signal
Socket.
Clean the switch assembly or
replace it with a new one.
Repair the trigger wire or replace it
with a new one.
Reprogram the WARFET for
the Stock Wiring mode.
